12 Kv Polymer Lightning Arrester

Name: 12 Kv Polymer Lightning Arrester
Brand: ELECTROMECH SERVICES
Price: 15000.00 -
Availability: InStock

Price 15000.00 - 18000.00 INR/ Set

Get a Price/Quote

MOQ : 1 Set

12 Kv Polymer Lightning Arrester Specification

Product Type
Pole Line Equipments

Material
Polymer

Welding Standard
N.A.

Application
Pole Line Fittings and Substation Fittings

Galvanization Standard
N.A.

Out Coating
N.A.

Standard
IEC Specifications

Shape
Round

Surface Treatment
N.A.

Height
As per drawing Millimeter (mm)

Design
As per Drawing

Thickness
As per Drawing Millimeter (mm)

Color
Grey

Warranty
12 Months

12 Kv Polymer Lightning Arrester Trade Information

Minimum Order Quantity
1 Set

FOB Port
HOWRAH/ KOLKATA

Payment Terms
Cheque, Telegraphic Transfer (T/T), Cash Advance (CA)

Supply Ability
100 Sets Per Month

Delivery Time
30-45 Days

Packaging Details
Corrugated Box or HDPE Bags

Main Domestic Market
All India

Certifications
Type Test & Routine Test Reports available.

About 12 Kv Polymer Lightning Arrester

12 Kv Polymer Lightning Arrester

12 KV Polymer Lightning Arrester Gapless type suitable for 11 KV Distribution Lines. Lightning Arresters are installed for protection of Electrical Equipments installed on the particular Pole or Substations from Lightning.

The Specifications read as under:

Highest System Voltage; 12 kV
Nominal System Voltage: 11 kV
Rated System Voltage: 12 kV
Nominal Discharge Current: 10 kA
Creepage Distance: 300 mm
Applicable Standards: IEC: 60099-4 & IS: 3070-1993 (Part-3)
Accessories: Mounting Bracket, Terminal Connectors.

Advanced Lightning Protection Solution

Offering robust surge protection, the 12 kV Polymer Lightning Arrester is tailored for modern electrical installations. Its polymer construction ensures longevity, minimal maintenance, and superior insulation. Designed strictly as per client drawings and international IEC standards, this arrester provides confidence for pole line and substation applications.

Custom-Fit and Industry-Compliant

Designed to meet precise project requirements, all critical dimensions such as thickness and height align with specific drawings. Its adherence to IEC standards guarantees compatibility and reliable performance in diverse climate conditions across India, making it an excellent choice for large-scale infrastructure projects.

FAQs of 12 Kv Polymer Lightning Arrester:

Q: How is the 12 kV Polymer Lightning Arrester installed on pole lines or substation fittings?

A: The arrester is designed for straightforward installation onto pole lines and substation fittings. Since it requires no welding or surface treatments, it can be mounted by following the dimensional specifics outlined in the supplied drawing.

Q: What are the main benefits of using a polymer lightning arrester over traditional options?

A: Polymer lightning arresters offer superior insulation, corrosion resistance, lighter weight, and longer service life compared to conventional ceramic or porcelain types, enhancing safety and reducing maintenance demands.

Q: When should the arrester be replaced or inspected during its use?

A: It is recommended to inspect the arrester periodically, especially after severe lightning events. While the product comes with a 12-month warranty, regular checks help ensure continued performance throughout its operational life.

Q: Where can I use this 12 kV Polymer Lightning Arrester effectively?

A: This lightning arrester is suitable for use in pole line and substation fittings, accommodating a wide range of installations in distribution and transmission networks according to IEC specifications.

Q: What is the process for ordering custom dimensioned arresters?

A: To order, provide your specific design drawings detailing required height and thickness. The manufacturer uses these drawings to ensure each unit is tailored to your applications precise needs.

Q: How does the arrester ensure adherence to IEC specifications?

A: All design and manufacturing processes adhere to the latest IEC standards, guaranteeing electrical safety, durability, and performance in Indian utility environments.
