11 KV Polymer Double Break Isolator

11 KV Polymer Double Break Isolator
Send Inquiry
Product Code : 11KV-POLY-ISO-DB-400
Brand Name : Electromech Insulators & Switchgears
Price And Quantity
  • Minimum Order Quantity
  • 1 Set
  • Price
  • 7000.00-18000.00 INR/Set
Product Specifications
  • Product Type
  • Pole Line Equipments
  • Material
  • Polymer Insulators, Copper Contacts and G.I. Iron Channel
  • Welding Standard
  • As per Standard
  • Capacity
  • 33 KV
  • Application
  • Pole Line Fittings and Substation Fittings
  • Galvanization Standard
  • IS SPECIFICATION
  • Out Coating
  • Hot Dip Galvanized
  • Standard
  • IS Specifications
  • Shape
  • Rectangular
  • Surface Treatment
  • Polished
  • Height
  • As per drawing Millimeter (mm)
  • Voltage
  • 400-1250 Amps Ampere (amp)
  • Design
  • As per Drawing
  • Thickness
  • As per Drawing Millimeter (mm)
  • Color
  • Silver with Grey Polymer Insulators
  • Warranty
  • 12 Months
Product Description

11 Kv Double Break Polymer Isolators

Leveraging on our vast industry experience, we Manufacture and supply an extensive range of HT Air Break Isolators. It is manufactured using materials, procured from certified vendor of the industry. Our skilled professional manufactures the product as per ISS-9921 (Part-IV)-1985 reaffirmed 2002 and is suitable for horizontal mounting. The product consists of nonferrous knife and spring loaded contacts, arching horns of adequate section to break magnetizing current of the transformer. In addition, it also have horizontal G.I. Pipe of adequate length for phase separation and operation from ground level with operating handle complete in both ON and OFF position. All ferrous parts are hot dip galvanized and nonferrous parts are tinned duly to withstand weather conditions. We provide this HT Air Break Isolators (11 KV Isolator) in single and double break types as per Ampere.

 Features:

  • Light weight
  • Easy to install
  • Superior strength

ELECTROMECH make Gang Operated Air Break off load disconnecting switch, tilting type. Each pole consists of hot dip galvanized steel channel base with three Insulators per phase as per BSS/ISS/IEC. Nonferrous knife and spring loaded contacts, arching horns of adequate section to break magnetizing current of the transformer. Horizontal G.I. Pipe of adequate length for phase separation and operation from ground level with operating handle complete in both ON and OFF position. All ferrous parts are hot dip galvanized and nonferrous parts are tinned duly to withstand weather conditions. Manufactured generally in accordance with ISS suitable for horizontal mounting as per ISS-9921 (Part-IV)-1985 reaffirmed 2002.


Manufactured in single and double break types as per Ampere.

TECHNICAL SPECIFICATION

Usage/Application

OVERHEAD LINE

Power/Voltage

11 KV

Voltage Level

High-Voltage

Brand

ELELECTROMECH INSULATORS & SWITCHGEARS

Number Of Insulator

Current Rating (Amps)

200, 400, 630, 800, 1250 AMPS

Trade Information
  • FOB Port
  • Howrah
  • Payment Terms
  • Telegraphic Transfer (T/T), Cheque, Cash Advance (CA)
  • Supply Ability
  • 100 Set Per Month
  • Delivery Time
  • 30
  • Packaging Details
  • Wooden Boxes and Pipe accessories in loose bundles.
  • Main Domestic Market
  • All India
  • Certifications
  • Routine Test Report available.
